22
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
(CONNECTORS)
CN301 645 088 3286 SOCKET,PWB-PWB 16(N.S.P)
CN302 645 074 0190 PLUG,SIDE-ZR-SM4 (N.S.P)
COMPL PWB,TB-1
613 210 9048
(CAPACITOR)
C4901 303 382 2908 ELECT 10U M 16V
(RESISTOR)
R4901 301 037 5007 MT-GLAZE 0.000 ZA 1/10W
(CONNECTORS)
CN491 645 089 4466 PLUG,PWB-PWB 13P (N.S.P)
CN492 645 076 9757 PLUG,SIDE-ZR-SM4 (N.S.P)
CN494 645 074 0190 PLUG,SIDE-ZR-SM4 (N.S.P)
COMPL PWB,SY-1 F/W
613 211 3175
(SEMICONDUCTORS)
Q4001 305 129 2301 TR UMZ1N
Q4201 305 129 2301 TR UMZ1N
Q4320 305 131 0203 TR DTC144EUA
Q4321 305 131 0203 TR DTC144EUA
Q4350 305 092 4104 TR 2SC4081-R
(INTEGRATED CIRCUITS)
IC401 309 669 1909 IC TB62209FG
IC402 309 669 1909 IC TB62209FG
IC403 309 336 1201 IC TC4W66FU(BRA,F)
IC404 309 336 1201 IC TC4W66FU(BRA,F)
IC411 410 623 2907 IC UPD70F3728GC-8BT-A (N.S.P)
IC412 309 537 6104 IC BD4846G
IC413 410 626 3901 IC AT24C128-10TU-2.7
IC421 309 670 6405 IC EW-650B
IC422 309 670 6405 IC EW-650B
IC423 409 678 9900 IC EW-750B
IC424 409 678 9900 IC EW-750B
IC431 309 415 7704 IC TC74VHC14FT
IC432 309 534 2703 IC XC6201P332M
IC433 309 400 9102 IC TC7SET08FU
IC435 309 167 7205 IC NJM2406F
IC451 309 601 0502 IC BD9703FP-E2
IC452 309 601 0502 IC BD9703FP-E2
(DIODES)
D4320 307 198 4200 LED SML-010LT
D4321 307 198 4200 LED SML-010LT
D4401 307 210 1903 DIODE 1SS400
D4501 307 229 6807 DIODE RSX101M-30
D4521 307 229 6807 DIODE RSX101M-30
(OSCILLATOR)
X4001 645 053 8483 OSC,CERAMIC 10.000MHZ
(INDUCTORS)
L4001 645 068 9000 INDUCTOR,10U K
L4201 645 068 9000 INDUCTOR,10U K
L4301 645 068 9000 INDUCTOR,10U K
L4401 645 068 9000 INDUCTOR,10U K
L4501 645 058 0918 INDUCTOR,10U M
L4521 645 058 0918 INDUCTOR,10U M
L4801 645 058 0918 INDUCTOR,10U M
(CAPACITORS)
C4001 303 387 8707 CERAMIC 10U K 10V
C4002 303 155 1800 CERAMIC 0.01U K 25V
C4003 303 387 8707 CERAMIC 10U K 10V
C4004 303 155 1800 CERAMIC 0.01U K 25V
C4005 403 458 1405 ELECT 220U M 35V
C4006 303 155 1800 CERAMIC 0.01U K 25V
C4007 303 281 5208 CERAMIC 0.22U Z 16V
C4008 303 215 2907 CERAMIC 0.022U K 25V
C4009 303 157 6704 CERAMIC 560P K 50V
C4021 303 155 1800 CERAMIC 0.01U K 25V
C4201 303 387 8707 CERAMIC 10U K 10V
C4202 303 155 1800 CERAMIC 0.01U K 25V
C4203 303 387 8707 CERAMIC 10U K 10V
C4204 303 155 1800 CERAMIC 0.01U K 25V
C4205 403 458 1405 ELECT 220U M 35V
C4206 303 155 1800 CERAMIC 0.01U K 25V
C4207 303 281 5208 CERAMIC 0.22U Z 16V
C4208 303 215 2907 CERAMIC 0.022U K 25V
C4209 303 157 6704 CERAMIC 560P K 50V
C4221 303 155 1800 CERAMIC 0.01U K 25V
C4301 303 155 1800 CERAMIC 0.01U K 25V
C4302 303 387 8707 CERAMIC 10U K 10V
C4303 303 392 5005 CERAMIC 22U M 6.3V
C4304 303 164 0207 CERAMIC 0.1U Z 25V
C4305 303 164 0207 CERAMIC 0.1U Z 25V
C4350 303 215 2204 CERAMIC 0.01U K 50V
C4351 303 298 9602 CERAMIC 0.1U K 16V
C4353 303 298 9602 CERAMIC 0.1U K 16V
C4354 303 298 9602 CERAMIC 0.1U K 16V
C4355 303 381 4804 ELECT 100U M 6.3V
C4401 303 387 8707 CERAMIC 10U K 10V
C4402 303 155 1800 CERAMIC 0.01U K 25V
C4403 303 387 8707 CERAMIC 10U K 10V
C4404 303 155 1800 CERAMIC 0.01U K 25V
C4405 303 387 8707 CERAMIC 10U K 10V
C4410 303 155 1800 CERAMIC 0.01U K 25V
C4411 303 387 8707 CERAMIC 10U K 10V
C4420 303 387 8707 CERAMIC 10U K 10V
C4421 303 155 1800 CERAMIC 0.01U K 25V
C4430 303 387 8707 CERAMIC 10U K 10V
C4431 303 155 1800 CERAMIC 0.01U K 25V
C4440 303 387 8707 CERAMIC 10U K 10V
C4441 303 155 1800 CERAMIC 0.01U K 25V
C4450 303 387 8707 CERAMIC 10U K 10V
C4451 303 155 1800 CERAMIC 0.01U K 25V
C4501 303 452 7901 CERAMIC 2.2U K 100V
C4502 303 452 7901 CERAMIC 2.2U K 100V
C4503 303 378 3605 POS-SOLID 33U M 10V
C4504 303 372 7500 CERAMIC 2.2U K 6.3V
C4505 303 358 5506 CERAMIC 0.1U K 25V
C4506 303 420 7902 CERAMIC 10U K 16V
C4521 303 452 7901 CERAMIC 2.2U K 100V
C4522 303 452 7901 CERAMIC 2.2U K 100V
C4523 303 365 2604 OS-SOLID 22U M 16V
C4524 303 372 7500 CERAMIC 2.2U K 6.3V
C4525 303 358 5506 CERAMIC 0.1U K 25V
C4526 303 358 5506 CERAMIC 0.1U K 25V
C4527 303 365 2604 OS-SOLID 22U M 16V
C4601 303 164 0207 CERAMIC 0.1U Z 25V
C4801 303 358 5506 CERAMIC 0.1U K 25V
(RESISTORS)
R4001 301 167 0309 MT-FILM 10K DU 1/16W
R4002 301 241 3806 MT-GLAZE 24K DC 1/16W
R4003 301 036 7200 MT-GLAZE 4.7 JA 1/8W
R4004 301 036 7200 MT-GLAZE 4.7 JA 1/8W
R4005 301 036 7200 MT-GLAZE 4.7 JA 1/8W
R4006 301 036 7200 MT-GLAZE 4.7 JA 1/8W
R4007 301 036 7200 MT-GLAZE 4.7 JA 1/8W
R4008 301 036 7200 MT-GLAZE 4.7 JA 1/8W
R4017 301 113 6201 MT-GLAZE 3.6K JA 1/16W
R4021 301 241 2809 MT-GLAZE 3.3K DC 1/16W
R4023 301 241 5701 MT-GLAZE 18K DC 1/16W
R4024 301 167 0309 MT-FILM 10K DU 1/16W
R4025 301 166 9600 MT-FILM 5.1K DU 1/16W
R4201 301 241 5800 MT-GLAZE 22K DC 1/16W
R4202 301 167 2006 MT-FILM 62K DD 1/16W
R4203 301 036 8900 MT-GLAZE 5.6 JA 1/8W
R4204 301 036 8900 MT-GLAZE 5.6 JA 1/8W
R4205 301 036 8900 MT-GLAZE 5.6 JA 1/8W
R4206 301 036 8900 MT-GLAZE 5.6 JA 1/8W
R4207 301 036 8900 MT-GLAZE 5.6 JA 1/8W
R4208 301 036 8900 MT-GLAZE 5.6 JA 1/8W
R4217 301 113 6201 MT-GLAZE 3.6K JA 1/16W
R4221 301 241 5305 MT-GLAZE 10K DC 1/16W
R4223 301 241 4001 MT-GLAZE 27K DC 1/16W
R4224 301 167 0309 MT-FILM 10K DU 1/16W
R4225 301 166 9600 MT-FILM 5.1K DU 1/16W
R4301 301 105 4208 MT-GLAZE 33K JA 1/16W
R4303 301 105 4208 MT-GLAZE 33K JA 1/16W
R4305 301 105 4208 MT-GLAZE 33K JA 1/16W
R4307 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
