30
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
ELECTRICAL PARTS
Note:
1. Materials of Capacitors and Resistors are abbreviated as follows ;
Resistors Capacitors
MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor
MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor
OXIDE-MT Oxide Metallized Film Resistor TA-SOLID Tantalum Solid Capacitor
AL-SOLID Aluminum Solid Capacitor
NP-ELECT Non-Polarized Electrolytic Capacitor
OS-SOLID Aluminum Solid Capacitors with Organic
Semiconductive Electrolytic Capacitor
DL-ELECT Double Layered Electrolytic Capacitor
POS-SOLID Polymerized Organic Semiconductor Capacitor
2. Tolerance of Capacitor (10pF over) and Resistor are noted with follow symboles.
F ............1% G ............2% J ............5% K ............10%
M ..........20% N ..........30% Z ..........+80% ~ -20%
3. Capacitors
U : µF P : pF
4. Inductors
UH : µH MH : mH
5. N.S.P. : Not available as service parts.
COMPL PWB,CP-1 F/W
636 135 2635
(VARISTOR)
VA131 308 050 1207 VARISTOR AVR-M1608C120MT
(SEMICONDUCTORS)
Q1001 305 186 7301 TR UP04213 00
OR 305 181 1205 TR NSBC144EDXV6T5
OR 305 173 4009 TR PEMH2
OR 305 166 9509 TR EMH2
Q1002 305 168 3703 TR DTC144EM
OR 305 216 1200 TR RN1104MFV
OR 305 172 4703 TR UNR32A3
Q1301 305 168 3703 TR DTC144EM
OR 305 216 1200 TR RN1104MFV
OR 305 172 4703 TR UNR32A3
Q1401 405 218 3902 TR UP0431300
OR 305 167 0406 TR EMD12
OR 305 216 2108 TR RN4984FE
Q3002 405 218 3902 TR UP0431300
OR 305 167 0406 TR EMD12
OR 305 216 2108 TR RN4984FE
Q3004 305 208 9702 TR SSM3J16TE
Q3006 305 181 4909 TR 2SK3541
Q5003 405 218 4701 TR SSM3J120TU
Q5004 305 181 4909 TR 2SK3541
Q9001 405 220 5604 TR RUM003N02
Q9002 405 220 5604 TR RUM003N02
(INTEGRATED CIRCUITS)
IC101 409 702 4406 IC EV4X1,BGA (N.S.P)
IC102 410 700 7702 IC K5W121GLCM-AK50,BGA (N.S.P)
IC103 409 690 7403 IC TC7SG126FE
IC104 409 690 7403 IC TC7SG126FE
IC111 409 680 0704 IC AK8113L
IC151 409 679 4003 IC NJM2561F1A
IC181 409 697 3101 IC AK4649ECB-L,BGA (N.S.P)
IC182 409 677 2803 IC NJM2877F3-03
IC191 410 671 2508 IC TDA9989ET/C1,518,BGA (N.S.P)
IC302 409 684 6801 IC XC61GN2502H-
IC303 409 696 2501 IC TCS10NPU
IC501 410 699 0203 IC ADP50260006ACBZ,BGA (N.S.P)
IC504 409 702 5908 IC XC6221D502G
IC901 409 696 6202 IC XC6221B082G
IC902 409 690 0909 IC TK70628HC-G
IC903 409 690 0909 IC TK70628HC-G
IC951 409 701 6401 IC BU24025MWV
(DIODES)
D1901 407 261 8903 DIODE RB520S-30FJ
D5071 408 069 2308 DIODE PEMG4005EJ/DG-115
D5301 307 238 1206 DIODE CUS01,Q
(OSCILLATORS)
X1102 645 091 5208 OSC,CRYSTAL 48.00000MHZ
X5001 645 090 3298 OSC,CRYSTAL 32.768KHZ
(INDUCTORS)
L1002 645 094 0521 IMPEDANCE,33 OHM P
L1003 945 020 1869 INDUCTOR,750 OHM
L1004 645 094 0521 IMPEDANCE,33 OHM P
L1005 945 053 5476 IMPEDANCE,240 OHM P
L1006 645 053 2276 IMPEDANCE,5 OHM P
L1007 645 072 0567 IMPEDANCE,470 OHM P
L1008 645 072 0567 IMPEDANCE,470 OHM P
L1009 645 053 5451 IMPEDANCE,600 OHM P
L1010 645 053 5451 IMPEDANCE,600 OHM P
L1011 645 053 5451 IMPEDANCE,600 OHM P
L1301 645 095 6522 FILTER,EMI 90 OHM
L1303 945 053 5414 IMPEDANCE,1000 OHM P
L1304 945 053 5414 IMPEDANCE,1000 OHM P
L1901 645 090 9719 IMPEDANCE,90 OHM M
L1902 645 090 9719 IMPEDANCE,90 OHM M
L5021 645 098 1968 INDUCTOR,4.7U M
L5031 645 098 1968 INDUCTOR,4.7U M
L5061 645 098 1968 INDUCTOR,4.7U M
L5071 645 093 8153 INDUCTOR,2.2U
L5301 645 098 2002 INDUCTOR,2.2U M
(CAPACITORS)
C1001 303 381 8109 CERAMIC 1U K 6.3V
C1002 303 384 6508 CERAMIC 10U K 6.3V
C1005 303 384 6409 CERAMIC 4.7U K 6.3V
C1007 303 381 8109 CERAMIC 1U K 6.3V
C1008 303 338 0309 CERAMIC 0.1U K 10V
C1009 303 381 8109 CERAMIC 1U K 6.3V
C1010 303 276 1307 CERAMIC 1000P K 50V
C1011 303 338 0309 CERAMIC 0.1U K 10V
C1012 303 381 8109 CERAMIC 1U K 6.3V
C1013 303 338 0309 CERAMIC 0.1U K 10V
C1024 303 384 6508 CERAMIC 10U K 6.3V
C1025 303 338 0309 CERAMIC 0.1U K 10V
C1026 303 338 0309 CERAMIC 0.1U K 10V
C1028 303 338 0309 CERAMIC 0.1U K 10V
C1031 303 338 0309 CERAMIC 0.1U K 10V
C1033 403 473 7604 CERAMIC 10U M 6.3V
C1051 303 338 0309 CERAMIC 0.1U K 10V
C1052 303 338 0309 CERAMIC 0.1U K 10V
C1053 303 338 0309 CERAMIC 0.1U K 10V
C1057 303 338 0309 CERAMIC 0.1U K 10V
C1058 303 338 0309 CERAMIC 0.1U K 10V
C1063 303 338 0309 CERAMIC 0.1U K 10V
C1064 303 338 0309 CERAMIC 0.1U K 10V
C1066 303 338 0309 CERAMIC 0.1U K 10V
C1067 303 338 0309 CERAMIC 0.1U K 10V
C1101 303 276 1000 CERAMIC 0.01U K 16V
To Next Page
