15 Menu and Description
For Menu please refer Table 5 and 6
MENU SUB MENU CHANGE DESCRIPTION REMARK
rLdr (Relay Drive) r. FS FS. H <>FS. L Fail Safe Selection
FS.H/ FS.L:Fail Safe
High/Low
rLdr (Relay Drive) r.oPt o.Ind<>o.PUM Control Action Selection
Ind : Individual, PUM :
Pump
rLdr (Relay Drive) r. SP S.000<>S.100 Set point Only in Indi-
vidual Controlling
rLdr (Relay Drive) r.SPH h.001<>h.100 Higher Set point Only in
Pump Controlling
SPH must be higher
than SPL
rLdr (Relay Drive) r.SPL L.000 <>L.099 Lower Set point Only in
Pump Controlling
SPH must be higher
than SPL
rLdr (Relay Drive) r.Cd C.000 <>C.100 Cover Delay in Seconds
rLdr (Relay Drive) r.Ud U.000 <>U.100 Uncover Delay in Sec-
onds
SCAL (Scal Factor) SC.-H H.020<>H.100 Higher SCALE LEVEL SCAL-HIGH must be
20% or more Higher
than SCAL-LOW
SCAL (Scal Factor) SC.-L L.000<>L.080 Lower SCALE LEVEL SCAL-HIGH must be
20% or more Higher
than SCAL-LOW
dISP(Display) d.PER<>d.AmP Display Options PER
: Percentage, AmP :
mAmp
Table 5: Menu
