User Manual & Datasheet V 2.1
MENU SUB MENU CHANGE DESCRIPTION REMARK
trbu (Turbulence) t.001 <>t.010 Turbulence Immunity
vts (Vehicle Mode) 1 = ON 0 = OFF Immunity to vehicle gen-
erated fluctuations
Only usefully in Vehicle
Tracking Systems
c. ID Id.00 <>id.99 Communication ID of
Sensor on RS-485 Net-
work
Com (Communication
Settings)
c.bAU b.00.3<>b.38.4 Communication Baud
Rate 9.6 x 1000 =
9600bps and so on
Com (Communication
Settings)
c.Flo F.CMd<>F.AUt Flow Control
• CMD : Send data
when Commanded
• AUT : Send Data
Automatically
Com(Communication
Settings)
c.dur d.001<>d.250 Auto Data Sending Du-
ration in Seconds
(Flow : AUT)
othr o.LEN LE0.0 <>LE9.9 Probe Length in meters Only for optimization
othr o.PRF PR.1 <>PRF.9 Profile Only for optimization
InFo i.SEr 12345678 Serial No Factory Sated and Read
Only
InFo i.dAt 12345678 Mfd. Date in DD-MM-
YY format
Factory Sated and Read
Only
Table 6: Menu
16 RS-485 Serial Commands for
Communication with Capvel
For RS-485 Serial Commands please refer Table 7
COMMAND DESCRIP-
TION
COMMAND TO BE
SEND TO SENSOR
EXPECTED RESPONSE
FROM INSTRUMENT
EXPLAINATION
Level would be calculated
by dividing incoming five
digit number with 10.Please
note that:- Application Soft-
ware must have to take care
of any possible errors dur-
ing turn-on or off durations,
change in nature of service
material etc.
<A,PER?>or
<B,PER?>or
<a,PER?>or
<z,PER?>or
<Z,PER?>
<A,PER=01000,H>
<B,PER=01000,N>
<a,PER=00625,N>
<z,PER=00000,N>
<Z,PER=00000,L>
100.0% (OVER)
100.0% (NORMAL)
62.5% (NORMAL)
0% (NORMAL)
0%(LOW)
Table 7: Percentage Level Information
