8 Mechanical Specification
For Mechanical Specification please refer Table 1
PARAMETER VALUE
Housing Cast aluminium weather and Flame proof suitable for
mounting in hazardous area Gas Group IIA and IIB as per
IS-2148
Mounting
Integral with sense rod or probe with SS /MS(plated)
Screw - 1"/1 1/2" BSP/NPT (M)
Flanged - (As per your order)
Cable Entry 2 X 1/2"/3/4" BSP/NPT, Brass
Gland type Double Compression Gland
Sensing Fully or Partially Teflon Coated Rod, Flexible Probe SS316
Stilling Tube Pipe, GI / SS
Overall Dimensions Please refer enclosed probe drawing
Table 1: Mechanical Specifications
9 Electrical Specification
For Electrical Specification please refer Table 2
PARAMETER VALUE
Mains
Capvel-BT : 9V to 55V DC
Capvel-ICT : 9V to 30V DC
Power Consumption
Capvel-BT : Max. 0.5 watt @12 V
Capvel-ICT : Max. 1 watt @12 V
Table 2: Electrical Specifcations
10 Measurement Specification
For Measurement Specification please refer Table 3
PARAMETER VALUE
Measurement Span 15 to 3000 pf above Zero
Response Time 0.5 to 5 secs.( Adjustable )
Accuracy +/- 1% FSL or better
Electronics Ambient Temp. 0
C. to +60
C
Fail-Safe Feature Reverse Calibratable (Low Level: 20 mA, High Level: 4
mA)
Table 3: Measurement Specifications
