SBL and SBLG Series Wireless Clocks - Table of Contents
Interactive Hyperlinked PDF – Click on the topic and the document will go to the relevant
page. Clicking on the logo will take you back to the table of contents.
Table of Contents 2
Important Safety Instructions 3
Identify Your Clock 4 - 5
Wireless System Setup 6 - 7
Preparing for the Installation 8
Wall Mounted Clock Mechanical Installation 9 - 13
Dual-Faced / Flag Mounted Digital Clocks Overview 14
Dual-Faced / Flag Mounted Clock Mechanical Installation 15 - 22
Uniform Stage Installation 23 - 25
Jumper Switch Settings 26
Temperature Sensor Installation 27
Buzzer Installation 28
Wiring Diagram for 110/230VAC 29
Wiring Diagram for 24VAC/VDC 30
Inputs - Clock Settings - User Inputs 31
Outputs 32
Manual Controls 33 - 37
Accessing the Clock After it has been Installed 38
sbdconfig Installation 39 - 47
- Task Bar 48 - 49
- Display Settings 50
- Brightness Schedule 51
- Clock Settings 52
- Outputs 53
- Elapsed Timer 54
- Inputs 55 - 56
- Daylight Saving Time (DST) 57
Reading the Display 58
Frequently Asked Questions 59 - 60
Troubleshooting 61
Warranty 62
FCC Statements 63
Available with 3200 and 3300 models
Available with 3300 model only
