Internal alibi memory
optional:
130,000 Data sets
Optional: it is possible to use a 10,000e
A|D converter instead of or additional to
the internal 3,000e A|D converter.
Combics 2 supports 2 Weighing Points (Scale)
Resolution (verifiable, Class III)
3,000e or 2 + 3,000e (MR|MI)
smallest signal 0.672 μV/e
optional:
10,000e class III accord. EN 45501;
OIML R 76,
smallest signal 0.328 μV/e
Resolution (not verified)
smallest usable signal: 0.2 or 0.1 μV/d
Load Cell supply
8.4 V
Minimum load impedance
83 Ohm bis 2,000 Ohm
Measuring signal
0 mV to 29.4 mV
Measuring signal for dead load
0.45 mV to 6.3 mV
Power cable
Length 3 m
Technical Data
Housing
Material: stainless steel 1.4301
Ingress protection:
CAIS2: IP69K
CAISL2: IP44
RoHs conform
Display
LCD, back lit,
Weight value: 20 mm, 7 digit, 14 segments
Status Symbols
Keyboard
28 keys, foil
Data interface
RS232
optional:
RS232
RS485/422
Analogue output 0|4..20 mA, 0-10 V, 16-bit
Digital I|O (5 In- and 5 Outputs)
Profibus DP
Ethernet TCP|IP and Modbus TCP
Connection of digital SBI/XBPI scales instead
of the internal A|D Converter possible.
Supply of one digital platform possible.
Operating temperature range
-10°C to 40°C
Power Supply
100–240 V
AC
(-15%|+10%), 50–60 Hz,
max. 17 W/23 VA
optional:
15.5–24 V
DC
(±10%), max. 12 W
13–17 V
AC
(±10%), 50–60 Hz, max. 12 W
Battery operation
Optional:
External battery package
EX approval
Optional for use in zone 2 and 22
ATEX: II 3G Ex nA IIC T4 Gc
II 3D Ex tD IIIC T80°C Dc
Interference emission
Acc. to EN 61326-1,
Class B (IEC 61326-1)
Electrical safety
Acc. to EN 61010-1 (IEC 61010-1)
EN60950 (IEC950)
Interference immunity
Acc. to EN 61326-1,
industrial areas (IEC 61326-1)
Net weight
2.3 kg
