D
W
14
Specifications
General Specifications for the IF-... Models
Model IF..
Allowable ambient operating temperature °C –10 to +40 (+14°F to +104°F)
IP rating IP65 (painted models)
IP68 (stainless steel models)
The cables supplied with the weighing platforms as standard equipment are 6 m in length.
Capacities: Up to 3000 kg, with restrictions, when the load is distributed on the load plate.
Accessories (Options)
Order no.
Additional drive-on ramps available on request
Frame for pit installation available on request
For affixing the weighing platform to the floor:
Floor-mounting set YFP01I
Columns can be manufactured to order on request.
Dimensions
Designation GG IG II LG LI LL NL NN RN RR WR
D (mm) 600 800 800 1,000 1,000 1,000 1,250 1,250 1,500 1,500 2,000
W (mm) 600 600 800 600 800 1,000 1,000 1,250 1,250 1,500 1,500
Resolutions
Resolution 1 Resolution 2
weighing capacity: -L -l -LCE weighing capacities -NCE 2+ 3,000e
Weighing Weighing Resolution: Weighing Resolution:
capacity 15,000d 30,000d 1+ 3,000e capacity 1 Capacity 1 capacity 2 Capacity 2
in kg in g in g in g in kg in g in kg in g
150 10 5 50 60 20 150 50
300 20 10 100 150 50 300 100
600 50 20 200 300 100 600 200
1000 100 50 500 600 200 1,000 500
1500 100 50 500 600 200 1,500 500
3000 200 100 1,000 1,500 500 3,000 1,000
