Over/Under Checkweighing with Additional Requirements
Changing the Tolerance Limits
You can change the over/under tolerances between 0.1% and10%.
Tolerance limits Code
0.1% over/under deviation from the target 4 1 1
0.2% over/under deviation from the target 4 1 2
0.5% over/under deviation from the target 4 1 3
1.0% over/under deviation from the target * 4 1 4
1.5% over/under deviation from the target 4 1 5
2.0% over/under deviation from the target 4 1 6
2.5% over/under deviation from the target 4 1 7
3.0% over/under deviation from the target 4 1 8
5.0% over/under deviation from the target 4 1 9
10.0% over/under deviation from the target 4 1 10
Analog Display
You can use an analog marker (two segments) instead of the bar graph located
below the checkweighing indication.
Analog display Code
Off 8 5 1
Bar graph * 8 5 2
Analog marker 8 5 3
Automatic Data Output
“Acceptable” values can be printed out or transferred automatically. Data are
output once the readout has stabilized within the tolerance limits selected.
Following data output, this function will be blocked until the balance has been
completely unloaded.
Automatic data output Code
On 4 2 1
Off * 4 2 2
* = factory setting
