Example:
Totalizing weight values.
Settings (changes in the factory settings required for this example):
Setup: Application: Totalizing
Setup: PRTPROT: 7.7.x (COM1 interface)
then select the desired line items
Setup: PRTPROT: 7.9.x (“Print when CF pressed")
then select the desired line items
4. Place the weight on the
weighing platform
Weight value is displayed
O
5. Save the second weight value
in totalizing memory
G# + 1.346 kg The component data
T + 0.346 kg is printed automatically
N + 1.000 kg (configured printout)
n2
The transaction counter
value is increased by one,
and now shows “2"
W
6. Toggle the display between
individual and total value
c
7. End totalizing
*G + 1.346 g The total data record is
*N + 1.250 g printed as configured.
n2
-------------------
78
1. Place the first weight on the
weighing platform
Weight value is displayed
O
2. Save the first weight value
in totalizing memory
G# + 0.250 kg The component data is
T + 0.000 kg printed automatically
N + 0.250 kg (configured printout)
n1
The transaction counter
value is increased by 1.
3. Remove the first weight from
the weighing platform
