03005 / 03007
Technical specifications
- Accuracy is specified within one year after calibration; temperature:
18℃～ 28℃ ; relative humidity: ＜ 75％ .
- The form of the accuracy specification: ± ([reading%] + [least significant
digit])
DC voltage
Range Resolution Accuracy
4V 0.001V
±（0.5%+5）
40V 0.01V
400V 0.1V
600V 1V ±（1.0%+5）
- Input impedance: about 10MΩ
- Maximum allowable input voltage: 600V
- Size: 150×78×38 (mm)
- Weight: about 240g (including batteries and sheath)
AC voltage
Range Resolution Accuracy
400Mv 0.1mV ±（1%+5）
4V 0.001V ±（0.8%+5）
40V 0.01V
±（1.0%+5）
400V 0.1V
600V 1V
-Input impedance: about 10MΩ
-Frequency range: 40Hz~400Hz
-Display: sine wave rms (average response)
-Maximum allowable input voltage: 600V
The accuracy of the 10A range is valid from 20% to 100% of the range.
Note
