SATA 03005 - Page 27

-27-
ESPT JARUEN DE KO
03005 / 03007
DC current
Range Resolution Accuracy
4A 0.001A ±（1.0%+7）
10A 0.01A ±（1.5%+7）
-Overload protection: 10A/690V fast-blow fuse protection
-Maximum measured current: 10A (for measured current greater than 2A:
Duration ＜ 10s, measurement interval ＞ 15min)
AC current
Range Resolution Accuracy
4A 0.001A ±（1.5%+7）
10A 0.01A ±（2.5%+7）
The accuracy of the 10A range is valid from 20% to 100% of the range.
The accuracy of the 10A range is valid from 20% to 100% of the range.
Note
Note
-Overload protection: 10A/690V fast-blow fuse protection
-Frequency range: 40Hz-400Hz
-Display: sine wave rms (average response)
-Maximum measured current: 10A (for measured current greater than 2A:
duration ＜ 10s, measurement interval ＞ 15min)
Resistance
Range Resolution Accuracy
400Ω 0.1Ω ±（1.0%+5）
4kΩ 0.001kΩ
±（0.5%+5）40kΩ 0.01kΩ
400kΩ 0.1kΩ
4MΩ 0.001MΩ ±（1.5%+5）
40MΩ 0.01MΩ ±（3.0%+5）
