SATA 03005 - Page 28

-28-
ESPT JARUEN DE KO
03005 / 03007
Frequency (only for 03007 model)
Range
Input voltage range for voltage
frequency measurement
Resolution Accuracy
4.999Hz
1V rms-20V rms
0.001Hz
±(1.0%+5)
49.99Hz 0.01Hz
499.9Hz 0.1Hz
4.999kHz 0.00k1Hz
49.99kHz 2V rms-20V rms 0.01kHz
499.9kHz 4V rms-20V rms 0.1kHz
4.999MHz 10V rms-20v rms 0.001MHz
For
reference
only
1. When measuring current frequency, the measured current must be
greater than 2A.
2. In the Frequency position, the range conversion is automatic.
Note
Duty cycle (only for 03007 model)
Range Resolution Accuracy
5%-95% 0.1% ±（2%+3）
- Input voltage: 4Vp-p ～ 10Vp-p
- Frequency range: 4Hz~1kHz
Capacitance
Range Resolution Accuracy
51.2Nf 0.01nF ±（3.5+20）
512.0nF 0.1nF ±（2.5%+5）
5.120μF 0.001μF
±（5.0%+5）
51.20μF 0.01μF
100.0μF 0.1μF
