Operating Instructions SATA vision 2000
Push SATA air warmer [1-14] onto SATA activated charcoal absorber
[1-7].
Connect air hose [1-3] to air connection [1-12].
Connect safety air hose [1-9] to the air connection of the belt unit.
Set the necessary air volumetric ow rate of the air control valve of the
activated charcoal absorber for breathing air / SATA air warmer.
The breathing protection equipment is operationally ready.
Variant 2 [2]
Connect gun compressed air hose [2-5] to the air connection of the
paint spray gun.
Connect gun compressed air hose to the air connection of the lter unit.
Take the air hose through the belt unit.
Connect air hose [2-3] to the air connection for breathing air [2-11].
Option
Connect top air humidier [2-4] to air hose [2-3] and air connection
[2-11].
Connect SATA air warmer [2-12] to air connection [2-11].
Connect safety air hose [2-6] to the air connection of the belt unit.
Set the necessary air volumetric ow rate at the air control valve / SATA
air warmer.
The breathing protection equipment is operationally ready.
Variant 3 [3]
Connect gun compressed air hose [3-5] to the air connection of the
paint spray gun.
Connect gun compressed air hose to air connection [3-6] of the air
control valve T-piece [3-7].
Take the air hose through the belt unit.
Connect air hose [3-3] to the air connection for breathing air [3-12] of
the T -piece.
Option
Connect top air humidier [3-4] to air hose [3-3] and air connection
[3-12].
Connect safety air hose [3-8] to the air connection of the T-piece of the
belt unit.
Connect SATA air warmer [3-14] to air connection [3-12].
Set the necessary air volumetric ow rate at the air control valve / SATA
