SATAM ZC 17-24 User Manual

Edition du 29/03/12 7/16 U508113-e Révision 4
5.2. A manifold
An aluminium manifold is mounted on the measuring chamber. The position of the gears differs according to the
position of the register.
Position 2 Position 1
