Satec EM133 Reference Guide

13
3 Device Register Map
3.1 Analog Registers, Binary Registers and Counters
Point
ID
Description
Options/Range
2
Units
2
Type
R/
W
Notes
0x0000
None
0
UINT16
R
Special Inputs
0x0101
Phase rotation order
0=error, 1=positive (ABC),
2=negative (CBA)
UINT16
R
0x0600
Digital Inputs DI1-D2
0x0000-0x0003
UINT16
R
Bitmap: 0=open, 1=closed
0x0800
Relay Output RO1
0x0000-0x0001
UINT16
R
Bitmap: 0=open, 1=closed
Counters
0x0A00
Counter #1
0-999,999,999
UINT32
R/W
0x0A01
Counter #2
0-999,999,999
UINT32
R/W
0x0A02
Counter #3
0-999,999,999
UINT32
R/W
0x0A03
Counter #4
0-999,999,999
UINT32
R/W
1-Cycle Phase Values
0x0C00
V1/V12 Voltage
0-Vmax
U1
UINT32
R
1
0x0C01
V2/V23 Voltage
0-Vmax
U1
UINT32
R
1
0x0C02
V3/V31 Voltage
0-Vmax
U1
UINT32
R
1
0x0C03
I1 Current
0-Imax
U2
UINT32
R
0x0C04
I2 Current
0-Imax
U2
UINT32
R
0x0C05
I3 Current
0-Imax
U2
UINT32
R
0x0C06
kW L1
-Pmax-Pmax
U3
INT32
R
0x0C07
kW L2
-Pmax-Pmax
U3
INT32
R
0x0C08
kW L3
-Pmax-Pmax
U3
INT32
R
0x0C09
kvar L1
-Pmax-Pmax
U3
INT32
R
0x0C0A
kvar L2
-Pmax-Pmax
U3
INT32
R
0x0C0B
kvar L3
-Pmax-Pmax
U3
INT32
R
0x0C0C
kVA L1
0-Pmax
U3
UINT32
R
0x0C0D
kVA L2
0-Pmax
U3
UINT32
R
0x0C0E
kVA L3
0-Pmax
U3
UINT32
R
0x0C0F
Power factor L1
-1000-1000
0.00
1
INT16
R
0x0C10
Power factor L2
-1000-1000
0.00
1
INT16
R
0x0C11
Power factor L3
-1000-1000
0.00
1
INT16
R
0x0C12
V1/V12 Voltage THD
0-9999
0.1
%
UINT16
R
1
2-cycle value
0x0C13
V2/V23 Voltage THD
0-9999
0.1
UINT16
R
1
2-cycle value
