Satec EM133 Reference Guide

14
Point
ID
Description
Options/Range
2
Units
2
Type
R/
W
Notes
%
0x0C14
V3/V31 Voltage THD
0-9999
0.1
%
UINT16
R
1
2-cycle value
0x0C15
I1 Current THD
0-9999
0.1
%
UINT16
R
2-cycle value
0x0C16
I2 Current THD
0-9999
0.1
%
UINT16
R
2-cycle value
0x0C17
I3 Current THD
0-9999
0.1
%
UINT16
R
2-cycle value
0x0C18
I1 K-Factor
10-9999
0.1
UINT16
R
2-cycle value
0x0C19
I2 K-Factor
10-9999
0.1
UINT16
R
2-cycle value
0x0C1A
I3 K-Factor
10-9999
0.1
UINT16
R
2-cycle value
0x0C1B
I1 Current TDD
0-1000
0.1
%
UINT16
R
2-cycle value
0x0C1C
I2 Current TDD
0-1000
0.1
%
UINT16
R
2-cycle value
0x0C1D
I3 Current TDD
0-1000
0.1
%
UINT16
R
2-cycle value
0x0C1E
V12 Voltage
0-Vmax
U1
UINT16
R
0x0C1F
V23 Voltage
0-Vmax
U1
UINT16
R
0x0C20
V31 Voltage
0-Vmax
U1
UINT16
R
1-Cycle Total Values
0x0F00
Total kW
-Pmax-Pmax
U3
INT32
R
0x0F01
Total kvar
-Pmax-Pmax
U3
INT32
R
0x0F02
Total kVA
0-Pmax
U3
UINT32
R
0x0F03
Total PF
-1000-1000
0.00
1
INT16
R
0x0F04
Total PF lag
0-1000
0.00
1
UINT16
R
0x0F05
Total PF lead
0-1000
0.00
1
UINT16
R
0x0F06
Total kW import
0-Pmax
U3
UINT32
R
0x0F07
Total kW export
0-Pmax
U3
UINT32
R
0x0F08
Total kvar import
0-Pmax
U3
UINT32
R
0x0F09
Total kvar export
0-Pmax
U3
UINT32
R
0x0F0A
3-phase average L-N/L-L voltage
0-Vmax
U1
UINT32
R
1
0x0F0B
3-phase average L-L voltage
0-Vmax
U1
UINT32
R
0x0F0C
3-phase average current
0-Imax
U2
UINT32
R
1-Cycle Auxiliary Values
0x1000
Not used
UINT32
R
0x1001
In (neutral) Current
0-Imax
U2
UINT32
R
0x1002
Frequency
0-Fmax
0.01
UINT16
R
