Satec EM133 Reference Guide

15
Point
ID
Description
Options/Range
2
Units
2
Type
R/
W
Notes
Hz
0x1003
Voltage unbalance
0-3000
0.1
%
UINT16
R
0x1004
Current unbalance
0-3000
0.1
%
UINT16
R
Phasor
0x1080
V1/V12 Voltage magnitude
0-Vmax
U1
UINT32
R
1
0x1081
V2/V23 Voltage magnitude
0-Vmax
U1
UINT32
R
1
0x1082
V3/V31 Voltage magnitude
0-Vmax
U1
UINT32
R
1
0x1083
Not used
UINT32
R
0x1084
I1 Current magnitude
0-Imax
U2
UINT32
R
0x1085
I2 Current magnitude
0-Imax
U2
UINT32
R
0x1086
I3 Current magnitude
0-Imax
U2
UINT32
R
0x1087
Not used
UINT32
R
0x1088
V1/V12 Voltage angle
-1800-1800
0.1º
INT16
R
1
0x1089
V2/V23 Voltage angle
-1800-1800
0.1º
INT16
R
1
0x108A
V3/V31 Voltage angle
-1800-1800
0.1º
INT16
R
1
0x108B
Not used
INT16
R
0x108C
I1 Current angle
-1800-1800
0.1º
INT16
R
0x108D
I2 Current angle
-1800-1800
0.1º
INT16
R
0x108E
I3 Current angle
-1800-1800
0.1º
INT16
R
0x108F
Not used
INT16
R
1-Second Phase Values
0x1100
V1/V12 Voltage
0-Vmax
U1
UINT32
R
1
0x1101
V2/V23 Voltage
0-Vmax
U1
UINT32
R
1
0x1102
V3/V31 Voltage
0-Vmax
U1
UINT32
R
1
0x1103
I1 Current
0-Imax
U2
UINT32
R
0x1104
I2 Current
0-Imax
U2
UINT32
R
0x1105
I3 Current
0-Imax
U2
UINT32
R
0x1106
kW L1
-Pmax-Pmax
U3
INT32
R
0x1107
kW L2
-Pmax-Pmax
U3
INT32
R
0x1108
kW L3
-Pmax-Pmax
U3
INT32
R
0x1109
kvar L1
-Pmax-Pmax
U3
INT32
R
0x110A
kvar L2
-Pmax-Pmax
U3
INT32
R
0x110B
kvar L3
-Pmax-Pmax
U3
INT32
R
0x110C
kVA L1
0-Pmax
U3
UINT32
R
0x110D
kVA L2
0-Pmax
U3
UINT32
R
0x110E
kVA L3
0-Pmax
U3
UINT32
R
0x110F
Power factor L1
-1000-1000
0.00
1
INT16
R
0x1110
Power factor L2
-1000-1000
0.00
1
INT16
R
