Satec EM133 Reference Guide

16
Point
ID
Description
Options/Range
2
Units
2
Type
R/
W
Notes
0x1111
Power factor L3
-1000-1000
0.00
1
INT16
R
0x1112
V1/V12 Voltage THD
0-9999
0.1
%
UINT16
R
1
3-sec value
0x1113
V2/V23 Voltage THD
0-9999
0.1
%
UINT16
R
1
3-sec value
0x1114
V3/V31 Voltage THD
0-9999
0.1
%
UINT16
R
1
3-sec value
0x1115
I1 Current THD
0-9999
0.1
%
UINT16
R
3-sec value
0x1116
I2 Current THD
0-9999
0.1
%
UINT16
R
3-sec value
0x1117
I3 Current THD
0-9999
0.1
%
UINT16
R
3-sec value
0x1118
I1 K-Factor
10-9999
0.1
UINT16
R
3-sec value
0x1119
I2 K-Factor
10-9999
0.1
UINT16
R
3-sec value
0x111A
I3 K-Factor
10-9999
0.1
UINT16
R
3-sec value
0x111B
I1 Current TDD
0-1000
0.1
%
UINT16
R
3-sec value
0x111C
I2 Current TDD
0-1000
0.1
%
UINT16
R
3-sec value
0x111D
I3 Current TDD
0-1000
0.1
%
UINT16
R
3-sec value
0x111E
V12 Voltage
0-Vmax
U1
UINT16
R
0x111F
V23 Voltage
0-Vmax
U1
UINT16
R
0x1120
V31 Voltage
0-Vmax
U1
UINT16
R
1-Second Total Values
0x1400
Total kW
-Pmax-Pmax
U3
INT32
R
0x1401
Total kvar
-Pmax-Pmax
U3
INT32
R
0x1402
Total kVA
0-Pmax
U3
UINT32
R
0x1403
Total PF
-1000-1000
0.00
1
INT16
R
0x1404
Total PF lag
0-1000
0.00
1
UINT16
R
0x1405
Total PF lead
0-1000
0.00
1
UINT16
R
0x1406
Total kW import
0-Pmax
U3
UINT32
R
0x1407
Total kW export
0-Pmax
U3
UINT32
R
0x1408
Total kvar import
0-Pmax
U3
UINT32
R
0x1409
Total kvar export
0-Pmax
U3
UINT32
R
0x140A
3-phase average L-N/L-L voltage
0-Vmax
U1
UINT32
R
1
0x140B
3-phase average L-L voltage
0-Vmax
U1
UINT32
R
