Satec Expertmeter Series Reference Guide

20
Point
ID
Description
Options/Range
2
Units
2
Type
R/
W
Notes
0x1E27
H40 Harmonic magnitude
0-10000
0.01
%
UINT16
R
Fundamental Phase Values
2-cycle values
0x2900
V1/V12 Voltage
0-Vmax
U1
UINT32
R
1
0x2901
V2/V23 Voltage
0-Vmax
U1
UINT32
R
1
0x2902
V3/V31 Voltage
0-Vmax
U1
UINT32
R
1
0x2903
I1 Current
0-Imax
U2
UINT32
R
0x2904
I2 Current
0-Imax
U2
UINT32
R
0x2905
I3 Current
0-Imax
U2
UINT32
R
0x2906
kW L1
-Pmax-Pmax
U3
INT32
R
0x2907
kW L2
-Pmax-Pmax
U3
INT32
R
0x2908
kW L3
-Pmax-Pmax
U3
INT32
R
0x2909
kvar L1
-Pmax-Pmax
U3
INT32
R
0x290A
kvar L2
-Pmax-Pmax
U3
INT32
R
0x290B
kvar L3
-Pmax-Pmax
U3
INT32
R
0x290C
kVA L1
0-Pmax
U3
UINT32
R
0x290D
kVA L2
0-Pmax
U3
UINT32
R
0x290E
kVA L3
0-Pmax
U3
UINT32
R
0x290F
Power factor L1
-1000-1000
0.00
1
INT16
R
0x2910
Power factor L2
-1000-1000
0.00
1
INT16
R
0x2911
Power factor L3
-1000-1000
0.00
1
INT16
R
Fundamental Total Values
2-cycle values
0x2A00
Total fundamental kW
-Pmax-Pmax
U3
INT32
R
0x2A01
Total fundamental kvar
-Pmax-Pmax
U3
INT32
R
0x2A02
Total fundamental kVA
0-Pmax
U3
UINT32
R
0x2A03
Total fundamental PF
-1000-1000
0.00
1
INT16
R
Minimum 1-Cycle Phase Values
0x2C00
V1/V12 Voltage
0-Vmax
U1
UINT32
R
1
0x2C01
V2/V23 Voltage
0-Vmax
U1
UINT32
R
1
0x2C02
V3/V31 Voltage
0-Vmax
U1
UINT32
R
1
0x2C03
I1 Current
0-Imax
U2
UINT32
R
0x2C04
I2 Current
0-Imax
U2
UINT32
R
0x2C05
I3 Current
0-Imax
U2
UINT32
R
Minimum 1-Cycle Total Values
0x2D00
Total kW
-Pmax-Pmax
U3
INT32
R
0x2D01
Total kvar
-Pmax-Pmax
U3
INT32
R
0x2D02
Total kVA
0-Pmax
U3
UINT32
R
0x2D03
Total PF
0-1000
0.00
UINT32
R
Absolute value
