Satec Expertmeter Series Reference Guide

21
Point
ID
Description
Options/Range
2
Units
2
Type
R/
W
Notes
1
Minimum 1-Cycle Auxiliary Values
0x2E00
Not used
UINT32
R
0x2E01
In Current
0-Imax
U2
UINT32
R
0x2E02
Frequency
0-Fmax
0.01
Hz
UINT32
R
Maximum 1-Cycle Phase Values
0x3400
V1/V12 Voltage
0-Vmax
U1
UINT32
R
1
0x3401
V2/V23 Voltage
0-Vmax
U1
UINT32
R
1
0x3402
V3/V31 Voltage
0-Vmax
U1
UINT32
R
1
0x3403
I1 Current
0-Imax
U2
UINT32
R
0x3404
I2 Current
0-Imax
U2
UINT32
R
0x3405
I3 Current
0-Imax
U2
UINT32
R
Maximum 1-Cycle Total Values
0x3500
Total kW
-Pmax-Pmax
U3
INT32
R
0x3501
Total kvar
-Pmax-Pmax
U3
INT32
R
0x3502
Total kVA
0-Pmax
U3
UINT32
R
0x3503
Total PF
0-1000
0.00
1
UINT32
R
Absolute value
Maximum 1-Cycle Auxiliary Values
0x3600
Not used
UINT32
R
0x3601
In Current
0-Imax
U2
UINT32
R
0x3602
Frequency
0-Fmax
0.01
Hz
UINT32
R
Maximum Demands
0x3700
V1/V12 Maximum volt demand
0-Vmax
U1
UINT32
R
1
0x3701
V2/V23 Maximum volt demand
0-Vmax
U1
UINT32
R
1
0x3702
V3/V31 Maximum volt demand
0-Vmax
U1
UINT32
R
1
0x3703
I1 Maximum ampere demand
0-Imax
U2
UINT32
R
0x3704
I2 Maximum ampere demand
0-Imax
U2
UINT32
R
0x3705
I3 Maximum ampere demand
0-Imax
U2
UINT32
R
0x3706
Not used
UINT32
R
0x3707
Not used
UINT32
R
0x3708
Not used
UINT32
R
0x3709
Maximum kW import sliding window demand
0-Pmax
U3
UINT32
R
0x370A
Maximum kvar import sliding window demand
0-Pmax
U3
UINT32
R
0x370B
Maximum kVA sliding window demand
0-Pmax
U3
UINT32
R
0x3737
Not used
UINT32
R
0x370D
Not used
UINT32
R
0x370E
Not used
UINT32
R
0x370F
Maximum kW export sliding window demand
0-Pmax
U3
UINT32
R
0x3710
Maximum kvar export sliding window demand
0-Pmax
U3
UINT32
R
