Satec Expertmeter Series Reference Guide

22
Point
ID
Description
Options/Range
2
Units
2
Type
R/
W
Notes
0x3711
Not used
UINT32
R
0x3712
Not used
UINT32
R
0x3713
Not used
UINT32
R
0x3714
Not used
UINT32
R
0x3715
In Maximum ampere demand
0-Imax
U2
UINT32
R
TOU Parameters
0x3C00
Active tariff
0-7
UINT32
R
0x3C01
Active profile
0-15:
0-3 = Season 1 Profile #1-4,
4-7 = Season 2 Profile #1-4,
8-11 = Season 3 Profile #1-4,
12-15 = Season 4 Profile #1-4
UINT32
R
Scaled Analog Outputs
0x3C80
Analog output AO1
0-4095
UINT32
R/W
0x3C81
Analog output AO2
0-4095
UINT32
R/W
TOU Energy Register #1
0x3D00
Tariff #1 register
0-999,999,999
kWh
UINT32
R
0x3D01
Tariff #2 register
0-999,999,999
kWh
UINT32
R
…
R
0x3D07
Tariff #8 register
0-999,999,999
kWh
UINT32
R
TOU Energy Register #2
0x3E00
Tariff #1 register
0-999,999,999
kWh
UINT32
R
0x3E01
Tariff #2 register
0-999,999,999
kWh
UINT32
R
…
R
0x3E07
Tariff #8 register
0-999,999,999
kWh
UINT32
R
TOU Energy Register #3
0x3F00
Tariff #1 register
0-999,999,999
kWh
UINT32
R
0x3F01
Tariff #2 register
0-999,999,999
kWh
UINT32
R
…
R
0x3F07
Tariff #8 register
0-999,999,999
kWh
UINT32
R
TOU Energy Register #4
0x4000
Tariff #1 register
0-999,999,999
kWh
UINT32
R
0x4001
Tariff #2 register
0-999,999,999
kWh
UINT32
R
…
R
0x4007
Tariff #8 register
0-999,999,999
kWh
UINT32
R
Billing Summary Accumulated Demands
0x4500
Summary register #1 demand
0-Pmax
U3
UINT32
R
0x4501
Summary register #2 demand
0-Pmax
U3
UINT32
R
0x4502
Summary register #3 demand
0-Pmax
U3
UINT32
R
0x4503
Summary register #4 demand
0-Pmax
U3
UINT32
R
