Satec Expertmeter Series Reference Guide

23
Point
ID
Description
Options/Range
2
Units
2
Type
R/
W
Notes
Billing Summary Block Demands
0x4580
Summary register #1 demand
0-Pmax
U3
UINT32
R
0x4581
Summary register #2 demand
0-Pmax
U3
UINT32
R
0x4582
Summary register #3 demand
0-Pmax
U3
UINT32
R
0x4583
Summary register #4 demand
0-Pmax
U3
UINT32
R
Billing Summary Sliding Window Demands
0x4600
Summary register #1 demand
0-Pmax
U3
UINT32
R
0x4601
Summary register #2 demand
0-Pmax
U3
UINT32
R
0x4602
Summary register #3 demand
0-Pmax
U3
UINT32
R
0x4603
Summary register #4 demand
0-Pmax
U3
UINT32
R
Billing Summary Maximum Demands
0x4780
Summary register #1 maximum demand
0-Pmax
U3
UINT32
R
0x4781
Summary register #2 maximum demand
0-Pmax
U3
UINT32
R
0x4782
Summary register #3 maximum demand
0-Pmax
U3
UINT32
R
0x4783
Summary register #4 maximum demand
0-Pmax
U3
UINT32
R
TOU Maximum Demand Register #1
0x4800
Tariff #1 maximum demand
0-Pmax
U3
UINT32
R
0x4801
Tariff #2 maximum demand
0-Pmax
U3
UINT32
R
…
R
0x4807
Tariff #8 maximum demand
0-Pmax
U3
UINT32
R
TOU Maximum Demand Register #2
0x4900
Tariff #1 maximum demand
0-Pmax
U3
UINT32
R
0x4901
Tariff #2 maximum demand
0-Pmax
U3
UINT32
R
…
R
0x4907
Tariff #8 maximum demand
0-Pmax
U3
UINT32
R
TOU Maximum Demand Register #3
0x4A00
Tariff #1 maximum demand
0-Pmax
U3
UINT32
R
0x4A01
Tariff #2 maximum demand
0-Pmax
U3
UINT32
R
…
R
0x4A07
Tariff #8 maximum demand
0-Pmax
U3
UINT32
R
TOU Maximum Demand Register #4
0x4880
Tariff #1 maximum demand
0-Pmax
U3
UINT32
R
0x4881
Tariff #2 maximum demand
0-Pmax
U3
UINT32
R
…
R
0x4887
Tariff #8 maximum demand
0-Pmax
U3
UINT32
R
V1/V12 Harmonic Angles
1, 3
0x6400
H01 Harmonic angle
-1800-1800
0.1º
INT16
R
0x6400
H02 Harmonic angle
-1800-1800
0.1º
INT16
R
...
