Satec Expertmeter Series Reference Guide

24
Point
ID
Description
Options/Range
2
Units
2
Type
R/
W
Notes
0x6427
H40 Harmonic angle
-1800-1800
0.1º
INT16
R
V2/V23 Harmonic Angles
1, 3
0x6500
H01 Harmonic angle
-1800-1800
0.1º
INT16
R
0x6500
H02 Harmonic angle
-1800-1800
0.1º
INT16
R
...
0x6527
H40 Harmonic angle
-1800-1800
0.1º
INT16
R
V1/V31 Harmonic Angles
1, 3
0x6600
H01 Harmonic angle
-1800-1800
0.1º
INT16
R
0x6600
H02 Harmonic angle
-1800-1800
0.1º
INT16
R
...
0x6627
H40 Harmonic angle
-1800-1800
0.1º
INT16
R
I1 Harmonic Angles
3
0x6700
H01 Harmonic angle
-1800-1800
0.1º
INT16
R
0x6700
H02 Harmonic angle
-1800-1800
0.1º
INT16
R
...
0x6727
H40 Harmonic angle
-1800-1800
0.1º
INT16
R
I2 Harmonic Angles
3
0x6800
H01 Harmonic angle
-1800-1800
0.1º
INT16
R
0x6800
H02 Harmonic angle
-1800-1800
0.1º
INT16
R
...
0x6827
H40 Harmonic angle
-1800-1800
0.1º
INT16
R
I3 Harmonic Angles
3
0x6900
H01 Harmonic angle
-1800-1800
0.1º
INT16
R
0x6900
H02 Harmonic angle
-1800-1800
0.1º
INT16
R
...
0x6927
H40 Harmonic angle
-1800-1800
0.1º
INT16
R
0x7C00
Setpoint Status SP1-SP16
0x00000000-0x0000FFFF
UINT32
R
Bitmap: 0=released, 1=operated
NOTES:
1
Voltage and voltage harmonics readings: when the 4LN3, 3LN3 or 3BLN3 wiring mode is selected, the voltages will be line-to-neutral; for any other wiring mode, they will be line-to-line
voltages.
2
For volts, amps, power and frequency scales and units, refer to Section 4 ”Data Scales and Units”.
3
Harmonic angles are referenced to the fundamental voltage harmonic H01 on phase L1.
