Satec Expertmeter Series Reference Guide

25
3.2 Minimum/Maximum Log Registers
Point
ID
Description
Options/Range/Format
2
Units
2
Type
R
/
W
Notes
Minimum Phase Values
0xB000
0xB001
Min. V1/V12 Voltage
Timestamp
0-Vmax
F1
U1
sec
UINT32
UINT32
R
R
1
0xB002
0xB003
Min. V2/V23 Voltage
Timestamp
0-Vmax
F1
U1
sec
UINT32
UINT32
R
R
1
0xB004
0xB005
Min. V3/V31 Voltage
Timestamp
0-Vmax
F1
U1
sec
UINT32
UINT32
R
R
1
0xB006
0xB007
Min. I1 Current
Timestamp
0-Imax
F1
U2
sec
UINT32
UINT32
R
R
0xB008
0xB009
Min. I2 Current
Timestamp
0-Imax
U2
sec
UINT32
UINT32
R
R
0xB00A
0xB00B
Min. I3 Current
Timestamp
0-Imax
U2
sec
UINT32
UINT32
R
R
Minimum Total Values
0xB080
0xB081
Min. Total kW
Timestamp
-Pmax-Pmax
U3
sec
INT32
UINT32
R
R
0xB082
0xB083
Min. Total kvar
Timestamp
-Pmax-Pmax
U3
sec
INT32
UINT32
R
R
0xB084
0xB085
Min. Total kVA
Timestamp
0-Pmax
U3
sec
UINT32
UINT32
R
R
0xB086
0xB087
Min. Total PF
Timestamp
-1000-1000
0.001
sec
INT32
UINT32
R
R
Minimum Auxiliary Values
0xB100
0xB101
Not used
0
UINT32
UINT32
R
R
0xB102
0xB103
Min. In Current
Timestamp
0-Imax
U2
sec
UINT32
UINT32
R
R
0xB104
0xB105
Min. Frequency
Timestamp
0-Fmax
0.01Hz
sec
UINT32
UINT32
R
R
Maximum Phase Values
0xB200
0xB201
Max. V1/V12 Voltage
Timestamp
0-Vmax
U1
sec
UINT32
UINT32
R
R
1
0xB202
0xB203
Max. V2/V23 Voltage
Timestamp
0-Vmax
U1
sec
UINT32
UINT32
R
R
1
0xB204
0xB205
Max. V3/V31 Voltage
Timestamp
0-Vmax
U1
sec
UINT32
UINT32
R
R
1
0xB206
0xB207
Max. I1 Current
Timestamp
0-Imax
U2
sec
UINT32
UINT32
R
R
0xB208
Max. I2 Current
0-Imax
U2
UINT32
R
