Satec Expertmeter Series Reference Guide

32
Address
Description
Options/Range
Units
Type
R
/
W
Notes
+1
PT ratio
10 to 65000
0.1
UINT
16
R/
W
+2
CT primary current
1 to 10,000
A
UINT
16
R/
W
+3
Power block demand period
1,2,3,5,10,15,20,30,60 min,
255 = external synchronization
min
UINT
16
R/
W
If the external synchronization is selected,
the DI1 input is considered a pulse or KYZ
input. The pulse edge restarts the power
demand block accumulation interval.
+4
Volt/ampere demand period
0 to 1800
sec
UINT
16
R/
W
+5-7
Reserved
UINT
16
R
Read as 65535
+8
Number of blocks in a sliding window
1 to 15
UINT
16
R/
W
+9-10
Reserved
UINT
16
R
Read as 65535
+11
Nominal line frequency
25, 50, 60, 400
Hz
UINT
16
R/
W
+12
Maximum demand load current
0 to 10,000 (0 = CT primary
current)
A
UINT
16
R/
W
+13-17
Reserved
UINT
16
R
Read as 65535
+18
Nominal secondary voltage
10 to 690 V
UINT
16
R/
W
+19
Reserved
UINT
16
R
Read as 65535
+20
PT ratio multiplication factor
1, 10
UINT
16
R/
W
Device Options Setup
0x8700-
0x870E
+0
Power calculation mode
0=using reactive power:
S=f(P,Q),
1=using non-active power:
Q=f(S,P)
UINT
16
R
+1
Energy roll value
0=110
4
, 1=110
5
, 2=110
6
,
3=110
7
, 4=110
8
, 5=1x10
9
UINT
16
R
+2
Phase energy calculation mode
0=disabled, 1=enabled
UINT
16
R
+3-9
Reserved
UINT
16
R
Read as 65535
+10
Energy LED test mode
0=disabled, 1=Wh test, 2=varh
UINT
R
LED pulse rate is 10,000 pulses/kWh
