4 SATEL Installer Manual
10 - 24H silent - armed all the time, irrespective of whether the partition it is assigned to is
armed, or not. Violation of this zone will only send a “zone alarm” code to the
monitoring station.
11 - 24H fire - armed all the time, irrespective of whether the partition it is assigned to is
armed, or not; intended for the fire detectors.
If one of the control panel outputs is programmed as the FIRE DETECTORS
POWER SUPPLY, violation of the zone will actuate the alarm verification
mechanism and will signal alarm in the keypad. To perform the verification, control
panel disconnects momentarily power supply to the fire detectors and checks,
whether after reconnection of power supply the violation will be repeated within
90 seconds. If that’s the case, the control panel will send a "zone alarm" message
to the monitoring station, activate the FIRE ALARM and FIRE/BURGLARY
ALARM outputs and trigger the fire alarm (intermittent signal) in the keypad.
If there are no FIRE DETECTORS POWER SUPPLY outputs, the zone violation
will immediately send a "zone alarm" code to the monitoring station, activate the
FIRE ALARM and FIRE/BURGLARY ALARM type outputs, as well as trigger the
fire alarm (intermittent signal) in the keypad.
12 - arming - violation of this zone will arm the partitions the zone belongs to.
13 - silent arming - violation of this zone will arm in silent mode the partitions the zone
belongs to.
14 - disarming - violation of this zone will disarm the partitions the zone belongs to.
15 - no alarm action - violation of this zone will activate the ZONE VIOLATION type
outputs.
16 - arm/disarm - violation of this zone will arm the partitions the zone belongs to, end of
violation will disarm those partitions.
17 - delayed with signalling
- a delayed zone with the same function as the 01 type zone,
but with delay countdown signaling in keypads.
18 - arming with bypass - violation of this zone arms the partition the zone belongs to,
simultaneously bypassing the zones programmed as AUTO-BYPASS (see: FS16,
FS19).
19 - perimeter - zone armed since entering the access code and confirming it with the [#]
key (i.e. arming the partition). Violation of this zone during countdown of the "exit
delay" will trigger an alarm.
Reaction time for each zone can be programmed within 0.016 s to 4.08 s. For delayed zones,
an individual time delay can be set. The zones can be selectively bypassed and/or assigned
to any partition. In case of messaging to the telephone monitoring stations, five event codes
sending to the monitoring stations can be determined for each zone.
The CA-6 has an additional CTL input, which is intended for arming or disarming. It can
also be used for connecting the panic, fire or emergency button.
Outputs
The CA-6 is equipped with 5 programmable outputs: 3 high-current (2,2A) and 2 low-current
(50mA). The OUT1, OUT2 and OUT3 outputs are protected by special electronic fuses with
current limiters set at 2,2A. The control panel monitors presence of voltage, overload, and
signals trouble conditions at these outputs. When active and at positive polarization, the
above outputs will supply +12V for the load.
The OUT4 and OUT5 outputs (low-current, 50mA) control ground of the load – when active
and at the positive polarization programmed (+12V), these outputs are shorted to common
ground (0V), whereas they are open when inactive.
The +KPD keypad supply output is fitted with an electronic fuse with current limiter 1.5A.
