System description and installation
CA-64 SATEL
♦ Possibility to define the names of users and of majority of system components
(partitions, zones, outputs, modules). This facilitates the control and monitoring of
system as well as viewing of events memory.
♦ Monitoring is made with the use of four different telephone numbers (two stations,
each with a back-up number), with possibility to divide events into 8 identifiers.
Besides basic transmission formats, the control panel makes possible monitoring
in Ademco Contact ID format.
♦ Informing to 16 normal telephone numbers with the use of messages from voice
synthesisers (up to 16 messages) or pagers (64 digital messages). Reception of
message may be confirmed with code sent by means of the telephone set
keyboard (DTMF).
♦ Function of phone call answering, which enables checking the status of all control
panel partitions and controlling of outputs (up to 16 outputs). This function is
executed after user identification (each user may be assigned with a special
“phone call” code).
♦ Extended function of events printing, which enables event sorting. Event
descriptions are in accordance with format Ademco Contact ID list of events,
which makes the control panel printout correspond to the monitoring station
printout. Besides, the names of zones, modules and users are printed as they are
defined in the system.
♦ Additional function of control panel RS-232 port – control with an external modem
– makes possible to communicate via a typical external modem. In this case,
remote programming via telephone line and service are as quick as direct
programming via RS-232 port.
♦ Control based on time is possible due to 64 timers that operate on week work
cycle, with possibility to define exception periods. Additionally, each partition is
provided with its own timer (based on week cycle or day cycle), programmed by
the user authorized for this, to secure automatic arming and disarming.
♦ Facilitated performance of non-standard functions due to complex logic
operations at outputs.
♦ High-capacity event memory (6140 events), in which apart from the monitored
events also other events (user access, functions used, etc.) are stored..
SYSTEM COMPONENTS
The control panel is provided with communication buses for connection of modules to
improve hardware possibilities, moreover, software up-dating is possible, which
opens the way to easy system upgrading. The features mentioned above allow to
extend the system by new components, which will be developed in future, in order to
meet customer’s needs and requirements.
Below are described already existing system components.
Main board
♦ 16 zones programmed individually for configurations NO, NC, EOL, 2EOL/NO
and 2EOL/NC with testing the detector operation correctness. One of tens of
response types may be chosen for each zone.
♦ 16 outputs with a programmable way of operation with a possibility of selection
one of tens functions (including: 4 high-load outputs with electronic fuses and low-
load outputs designed for relays controlling).
