34
System description and installation
CA-64 SATEL
2. Connect the 220 VAC mains – the control panel starts to operate.
The sequence of power supply switching on specified here (first battery, then 220
VAC mains) ensures correct operation of power supply unit and control panel
electronic protections, what allows avoiding failures of alarm system components due
to installation errors. Start the modules with their own power supplies in the similar
way.
CAUTION!
In situation, when total disconnection of control panel power supply
(mains and battery) is necessary, switch on the control panel in the way
described above (first battery, then mains 220 VAC).
Stabilised voltage of control panel power supply unit is 13.6 - 13.8V, and it is factory
set.
After all wiring is made and installation correctness is confirmed, you may start the
system. It is recommended to start operation with the control panel without signalling
devices. The signalling devices may be connected after completion of parameter
programming for the alarm system.
For systems with extension modules with their own power supply, it is recommended
to start the control panel first, then other system components in sequence.
CAUTION !
Since the control panel is not provided with main switch to disconnect mains, it is
important to inform the alarm system owner or user on how to disconnect it from
mains (e.g. by showing the fuse protecting the control panel power supply circuit).
Staring the system
Starting of control panel after power supply is switched on is carried out in two
stages:
1) First program STARTER starts and checks contents of the control panel program
memory. During this operation, LED adjacent to telephone line transmitter flashes
and message STARTER 2.2 of control panel CA-64 is shown on LCD keypad
displays. When the contents of FLASH program memory is correct, STARTER
starts the program of the control panel.
2) The program the control panel starts with checking the memory of settings (RAM
memory with backup battery 3.6V/60mAh). If the differences, comparing to
settings programmed by service, are detected, proper settings will be restored
from FLASH memory (this test is skipped when control panel settings are not
stored in FLASH memory; question about storing the settings appears when
exiting service mode). The control panel starts to operate after settings are
checked.
NOTES:
• If the error in the control panel program is detected, the message “Download
correct program to the control panel” appears on LCD keypad displays and
STARTER program waits for new program from the computer. Error in program
may occur only when the control panel software up-dating process has been
stopped by switching power supply off.
• When the control panel is not powered, removal of jumper MEMORY causes
cancelling the contents of memory of settings, user data, event memory and
clock. After power supply is restored, the control panel restores memory of
