Satel PK-01 User Manual

SATEL PK-01 1
The PK-01 module is designed for single door control. The access control is effected by
means of electric control of the door status and user identification functions.
1. Features
 Support for up to 50 proximity cards (wherever the word "card" is used in this manual, it
means a passive transponder, which may take the form of a proximity card, proximity tag,
etc.), and for 50 codes.
 Programming the module and managing the cards and codes by means of the
administrator code.
 Ability to block and unblock the door by users with suitable authority level.
 Keypad with backlight.
 Bell button.
 Built-in reader for cards, tags and other 125 kHz passive transponders.
 LED indicators of the door and module status.
 Built-in piezoelectric transducer for sound signals.
 Relay output for control of electromagnetic lock, gate controllers or other devices to
activate the door.
 2 OC type outputs:
– indication of alarm status;
– bell signal.
 2 dedicated inputs to connect:
– door status sensor;
– request-to-exit button/device.
 Enclosure suitable for outdoor installation.
 Tamper protection in 2 ways – cover removal and tearing enclosure from the wall.
 Powered by 12 V DC (±15%).
2. Description
2.1 LED indicators
red
ON – alarm (signaling lasts 10 seconds);
blinking – alarm memory (signaling lasts until a code is entered or
a card is read in by any user).
The alarm can be caused by:
 forced entry,
 3 attempts to get access using unknown identifier (code or card),
 module tamper.
green
ON – the door is unblocked (permanently unlocked),
blinking – the door is unlocked (the user has gain access).
yellow
ON – the door is blocked (permanently locked).

Satel PK-01 Specifications

Power

supply voltage	12 V DC ±15%
standby current consumption	105 mA
maximum current consumption	125 mA

Operating Environment

maximum humidity	93±3%
operating temperature range	-25 to +55 °C
environmental class according to EN50130-5	III

Output Ratings

bell output rating	30 mA
alarm output rating	30 mA
relay contacts rating (resistive load)	2 A / 24 V DC

Frequency

reader working frequency	125 kHz

Weight and Dimensions

weight	297 g
enclosure dimensions	47 x 158 x 24 mm
