Satel PK-01 User Manual

8 PK-01 SATEL
 the key – permanent backlight.
3. Confirm with the key. The module will generate 4 short beeps and 1 long beep.
gs 7. Restoring factory settin
1. Turn off the module power supply.
2. Short the ends of the green and black wires.
3. Turn on the power supply. The module will generate 4 short beeps and 1 long beep. The
orresponding terminals.
er supply.
0 s
duction – function disabled
factory settings are restored.
4. Turn off the power supply again.
5. Open the ends of the green and black wires.
6. Connect the wires correctly to the c
7. Turn on the module pow
7.1 Factory settings
Administrator code: 12345
Door status input – unused
Request-to-exit input – unused
Maximum door open time –
Relay operation time – 5 s
Relay operation time re
Backlight – automatic
8. Specifications
Supply voltage ................................................................................................... 12 V DC ±15%
Standby current consumption ........................................................................................105 mA
Maximum current consumption ......................................................................................125 mA
Bell output rating ..............................................................................................................30 mA
Alarm output rating...........................................................................................................30 mA
Reader working frequency ............................................................................................125 kHz
Relay contacts rating (resistive load) ...................................................................2 A / 24 V DC
Environmental class according to EN50130-5 ........................................................................III
Maximum humidity ..........................................................................................................93±3%
Operating temperature range..................................................................................-25...+55 °C
Enclosure dimensions ................................................................................... 47 x 158 x 24 mm
Weight...............................................................................................................................297 g

Satel PK-01 Specifications

Power

supply voltage	12 V DC ±15%
standby current consumption	105 mA
maximum current consumption	125 mA

Operating Environment

maximum humidity	93±3%
operating temperature range	-25 to +55 °C
environmental class according to EN50130-5	III

Output Ratings

bell output rating	30 mA
alarm output rating	30 mA
relay contacts rating (resistive load)	2 A / 24 V DC

Frequency

reader working frequency	125 kHz

Weight and Dimensions

weight	297 g
enclosure dimensions	47 x 158 x 24 mm
