Fuses Usage
22 ABS Anti-Lock Brake System
23 RR DEFOG Rear Defog Mini Relay
38 RUN/CRANK Ignition 1 Mini Relay
39 IP BATT1 Body Control Module
40 ABS Anti-Lock Brake System
41 IP BATT2 Body Control Module
43 EPS Electric Power Steering
44 COOLING
FAN 2
Cooling Fan Mini Relay
45 COOLING
FAN 1
Cooling Fan Mini Relay
46 CRANK Crank
47 IP BATT 1A Body Control Module
48 RUN (IGN 3) Body Control Module
Relays Usage
24 A/C CLUTCH Air Conditioning Clutch
25 HORN Horn
27 AFTER
COOLER PUMP
After Cooler Pump
28 RUN/CRANK Body Control Module
29 POWERTRAIN
Powertrain
30 COOLING
FAN 1
Engine Cooling Fan
31 ECM CONT Starter Solenoid
32 WIPER1 Wiper System
33 WIPER2 Wiper System
34 REAR DEFOG Rear Window Defroster
Diodes Usage
35 A/C Air Conditioning Diode
37 WIPER Wiper Diode
5-101
To Next Page
