5. Push headlamp housing lever up to disengage
headlamp housing from headlamp housing
pocket.
6. Turn the bulb socket being replaced
counterclockwise one–quarter of a turn while
pressing the socket in firmly. Pull the socket
rearward until the bulb clears the headlamp housing,
and lift it up to access the bulb.
7. Disconnect the wire connector from the bulb by
lifting the lock tab and pulling it away from the
plastic base.
8. Remove the bulb assembly and replace it with the
appropriate bulb.
5-48
