Taillamps, Turn Signal, Stoplamps
and Back-up Lamps (Wagon)
1. Open the liftgate.
2. Remove the interior access trim panel.
3. Turn the bulb socket being replaced
counterclockwise one–quarter of a turn while
pressing the socket in firmly. Pull the socket
rearward until the bulb clears the taillamp housing.
4. Replace it with the appropriate bulb.
Replacement Bulbs
Exterior Lamp Bulb Number
Headlamps —
High Beam 9005 HB39441732
Low Beam 9006 HB49441733
Front Park/Turn Lamps 34571999381
Front Side Markert Lamps W5W12092811
Stop/Taillamps P21/5W21019520
Rear Turn Lamps P21W21019521
Back-up Lamps P21W21019520
CHMSL PC16825085970
Fog Lamps 880L12450143
5-52
