Fuses Usage
INJ Fuel Injectors (2.2L L4 (L61))
BACK-UP/TURN
Backup Lamps, Coolant Level
Switch
BRAKE Brake Lamps
FUEL PUMP Fuel Pump Relay
IGN 0
Park Neutral Position Switch,
Powertrain Control Module
CRUISE SW Cruise Control Switch
CONTROLS
IGN 1
Cooling Fan Control Module,
Powertrain Control Module,
Transaxle (2.2L L4 (L61)),
Transaxle Control Module
(3.0L V6 (L81))
IGN 1
Instrument Cluster, Coolant Level
Switch, Air Bag, Electronic
PRND321
BCM/CLUSTER
Body Control Module, Instrument
Cluster, Dimmer Switch
Fuses Usage
PARK LAMP
Front Park Lamps, Taillamps, Front
Marker Lamps, Rear Marker Lamps,
License Lamps, Radio Display
Lights, I/P Cluster Backlighting, I/P
Dimmer, Cigar Lighter Ring, Ashtray
Light, PRND321 Light, Climate
Control Switch Backlighting
HAZARD
Hazard Flasher, HBTT (Headlamp
HI Beam Indicator), I/P Cluster
REAR DEFOG Rear Window Defogger
RADIO/ON-STAR
Audio System, OnStar
®
, Rear Seat
DVD (Option)
CD/DLC
Audio, Data Link Connector, (DLC),
Rear Seat DVD (Option)
ING 3
Cruise Clutch Switch, Emissions
Controls, Air Conditioner Relay,
Heated Oxygen Sensor
ENG CNTL 1 3.0L V6 (L81) Engine
ENG CNTL 2 3.0L V6 (L81) Engine
ENG CNTL 3 3.0L V6 (L81) Engine
A/C DIODE Air Conditioner Diode
5-96
