Headlamps
A. Parking/Turn Signal Lamp
B. Low-beam Headlamp/Daytime Running Lamp (DRL)
C. High-beam Headlamp
To replace one of the headlamp bulbs, use the following
procedure. To replace the parking/turn signal lamp
bulb, see Front Turn Signal and Parking Lamps
on page 5-51.
1. Open the hood. See Hood Release on page 5-11
for more information.
2. Remove the two screws from the top of the front
fascia and grille. They are inboard of the headlamp
assembly.
5-49
