Fuses Usage
AUX 1 OUTLET Front Auxiliary Power Outlet
PREM AUD Premium Radio Amplifier
ABS Anti-lock Brake System Ignition
PWR SEAT Power Seats
Relays Usage
FOG LP Fog Lamps
COOL FAN
HI (L4)
Cooling Fan Motor High
ENG MAIN
Engine Control Module/CAM,
Emissions, Injectors,
Electronic Throttle Control
REAR DEFOG Rear Defog System
HORN Horn
DRL Daytime Running Lamps
COOL FAN 1
(V6)
Cooling Fan
WIPER
SYSTEM
Wiper System
Relays Usage
PRW WDO
Power Window Switch,
Sunroof Module
FRT WIPER Front Wiper System
COOL FAN
LOW (L4)
Cooling Fan Motor Low
A/C CLUTCH Air Conditioning Clutch
BACKUP
LAMPS (V6)
Back-up Lamps (V6)
FUEL PUMP Fuel Pump System
RR WIPER Rear Wiper System
COOL FAN 2
(V6)
Cooling Fan (V6)
Misc. Usage
FUSE PULLER Fuse Puller
Diode Air Conditioning Diode
5-98
