Fuses Usage
BCM (VB2) Body Control Module (VB2)
DRL Daytime Running Light
BCM (VB1) Body Control Module (VB1)
ONSTAR OnStar
®
Relays Usage
RELAY
ACC/RAP
Accessory, Retained Accessory
Power (RAP) Relay
RELAY
RUN/CRANK
Run/Crank Relay
Underhood Fuse Block
Main Underhood Fuse Block
The main underhood fuse block is located on the driver
side of the engine compartment. The main underhood
fuse block is the larger of the two fuse blocks in the
engine compartment. Remove the fuse block cover for
access to the fuses and relays. See Engine Compartment
Overview on page 5-12 for more information on its
location. To remove fuses, hold the end of the fuse
between your thumb and index finger and pull straight
out or use the fuse puller located inside the fuse block.
Notice: Spilling liquid on any electrical components
on your vehicle may damage it. Always keep the
covers on any electrical component.
5-93
