Saturn 2008 VUE Green Line Hybrid - Page 333

Fuses Usage
A/C COMP Air Conditioning Compressor
MAIN
Engine Control Module/CAM,
Emissions, Injectors,
Electronic Throttle Control
FUEL Fuel Pump
AWD Not Used
ABS
Anti-lock Brake System
Module (ABS)
STOP Stoplamp
HEATING MAT Heating Mat
HORN Horn
WIPER Windshield Wiper
SUNROOF* Sunroof (Option)
ANTI-THEFT* Theft Deterrent System (Option)
POWER
SEAT*
Power Seat (Option)
Fuses Usage
HDLP LO LH Left Headlamp Low-Beam
HDLP LO RH Right Headlamp Low-Beam
PKLP LH Left Parking Lamp
FRT FOG Front Fog Lamps
H/L HI H/L High
BLANK Not Used
HDLP
WASHER
Headlamp Washer
TCM Transmission Control Module
T/PKLP L H Left Turn Signal and Parking Lamp
SPARE Spare
SPARE Spare
SPARE Spare
SPARE Spare
5-95
