Fuses Usage
ENG-3 Engine 3
ENG-2 Engine 2
ENG-1 Engine 1
HYBRID BEC Hybrid Auxiliary BEC
RUN Run
S/ROOF Sunroof Module
HTD/SEAT Heated Seat Control Module
BCM Body Control Module
STRTR Starter Motor
WPR Windshield Wiper
4WD/ESCM All-Wheel Drive System
ABS Antilock Brake System Module
A/C CLTCH Air Conditioning Compressor
BLWR MTR Blower Motor
AMP Amplifier
HORN Horn
ABS Antilock Brake System Module
Fuses Usage
I/P BEC
Instrument Panel Bussed Electrical
Center
FRT FOG Front Fog Lamps
I/P BEC
Instrument Panel Bussed Electrical
Center
DRL Daytime Running Light
T/LAMP RT Right Turn and Parking Lamps
T/LAMP LT Left Turn and Parking Lamps
TRLR T/LAMP Trailer Parking Lamps
HDLPHILT
Passenger Side High-Beam
Headlamp
STOP LP Stoplamps
DEFOG Defroster Fog
HDLP LO RT Driver Side Low-Beam Headlamp
HDLP LO LT
Passenger Side Low-Beam
Headlamp
HDLP RT HI Driver Side High-Beam Headlamp
OSRVM HTR Outside Rearview Mirror Heating
5-102
