Relays Usage
FAN MAIN
RLY
Cooling Fan Main Relay
FAN CTRL
RLY
Cooling Fan Control Relay
FAN AUX RLY Cooling Fan Auxiliary Relay
PWR/TRN RLY
Engine Control Module/CAM,
Canister, Injectors, Electronic
Throttle Control Relay
STRTR RLY Starter Relay
RUN RLY Run Relay
A/C CLTCH
RLY
Air Conditioning Compressor Relay
Relays Usage
WPR SPD RLY Windshield Wiper Speed Relay
HORN RLY Horn Relay
WPR CNTRL
RLY
Windshield Wiper Control Relay
T/LAMP RLY Parking Lamp Relay
HDLP HI RLY High-Beam Headlamp Relay
HDLP LO RLY Low—Beam Headlamp Relay
FRT FOG RLY Front Foglamp Relay
STOP LP RLY Stoplamp Relay
DEFOG RLY Defroster Fog Relay
