Engine Compartment Overview
When you open the hood on the 2.4L L4 engine, you will see the following:
A. See Engine Air Cleaner/Filter on
page 5-17.
B. Electric Engine Cooling Fan (Out
of View). See Cooling System on
page 5-19.
C. Engine Oil Dipstick (Out of View).
See “Checking Engine Oil” under
Engine Oil on page 5-14.
D. Engine Oil Fill Cap (Out of View).
See “When to Add Engine Oil”
under Engine Oil on page 5-14.
E. Brake Fluid Reservoir. See
Brakes on page 5-28.
F. Engine Coolant Surge Tank. See
“Checking Coolant” under Engine
Coolant on page 5-22.
G. Remote Positive (+) Terminal.
See Jump Starting on page 5-31.
H. See Underhood Fuse Block
on page 5-82.
I. See Battery on page 5-30.
J. Windshield Washer Fluid
Reservoir. See “Adding Washer
Fluid” under Windshield
Washer Fluid on page 5-27.
5-12 Service and Appearance Care
