Fuses Usage
BCM (VB4)
Body Control
Module (VB4)
BCM (VB5)
Body Control
Module (VB5)
TRL Trailer
AIRCON Air Conditioner
AUDIO Audio
BCM (VB7)
Body Control
Module (VB7)
IGN SW Ignition Switch
AIR BAG Air Bag System
WASHER Washer Pump
APO1
Accessory Power
Outlet 1
Fuses Usage
FSCM
Fuel Storage Control
Module
RR CLR Rear Closure
BCM (VB2)
Body Control
Module (VB2)
DRL
Daytime Running
Light
BCM (VB1)
Body Control
Module (VB1)
ONSTAR OnStar
®
Relays Usage
RELAY
ACC/RAP
Accessory, Retained
Accessory Power
(RAP) Relay
RELAY
RUN/
CRANK
Run/Crank Relay
Underhood Fuse Block
The underhood fuse block is located
on the driver side of the engine
compartment, near the battery.
Notice: Spilling liquid on
any electrical components on the
vehicle may damage it. Always
keep the covers on any electrical
component.
