Sauder 402159 - Step 14: Keyboard Front Hinge Attachment

å
Fasten the HINGES (H1) to the KEYBOARD FRONT (M).
Use four BLACK 9/16" LARGE HEAD SCREWS (S6).
å
Fasten the KEYBOARD FRONT (M) to the KEYBOARD
SHELF (U). Use four BLACK 9/16" LARGE HEAD
SCREWS (S6).
å
NOTE: As shown in the bottom enlarged diagrams, the
KEYBOARD FRONT (M) can be latched to the KEYBOARD
SIDES by pushing on the LATCH release. The KEYBOARD
FRONT (M) can be adjusted horizontally and vertically by
loosening the screws and sliding them one way or another
in the HINGE slots for the latch work properly.
Step 14
BLACK 9/16" FLAT HEAD SCREW
(8 used in this step)
S6
M
M
M
M
M
M
H1
U
U
U
S6
V
W
AND
V
W
AND
Page 18 www.sauder.com 402159
Push to release
