å
First, fi ll the holes in the short edge of the LEFT END (C) a 1/4
to 1/2 full with GLUE (G1).
Then, use your hammer to tap
two
DOWELS (R1) into the holes. Wipe away the excess GLUE.
å
Tap two FEET (F1) into the other short edge of the LEFT END (C)
as shown.
å
Fasten three CORNER BRACKETS (T1) to the long edge of the
LEFT END (C). Use three BLACK 1/2" PAN HEAD SCREWS (S7).
å
NOTE: Be sure the edges of the BRACKETS are even with the
long edge of the LEFT END.
å
Turn two PINS (Q1) into the LEFT END (C) as shown.
Step 2
Q1
Q1
F1
R1
C
T1
(3 used)
BLACK 1/2" PAN HEAD SCREW
(3 used in this step)
S7
Page 6 www.sauder.com 402159
G1
G1
To Next Page
