Sauder 402159 - Step 5: Right End Panel Assembly

å
First, fi ll the holes in the short edge of the RIGHT END (F)
a 1/4 to 1/2 full with GLUE (G1). Then, use your hammer
to tap two DOWELS (R1) into the holes. Wipe away the
excess GLUE.
å
Tap two FEET (F1) into the other short edge of the RIGHT
END (F) as shown.
å
Fasten three CORNER BRACKETS (T1) to the long edge
of the RIGHT END (F). Use three BLACK 1/2" PAN HEAD
SCREWS (S7).
å
NOTE: Be sure the edges of the BRACKETS are even with
the long edge of the RIGHT END.
å
Turn two PINS (Q1) into the RIGHT END (F) as shown.
Step 5
Q1
T1
(3 used)
BLACK 1/2" PAN HEAD SCREW
(3 used in this step)
S7
F1
Page 9
www.sauder.com402159
F
R1
G1
G1
Q1
