Sauder 402159 - Step 4: Right Upright Panel Assembly

å
First, fi ll the holes in the short edge of the RIGHT
UPRIGHT (E) a 1/4 to 1/2 full with GLUE (G1). Then, use your
hammer to tap two DOWELS (R1) into the holes. Wipe away
the excess GLUE.
å
Tap two FEET (F1) into the other short edge of the RIGHT
UPRIGHT (E) as shown.
å
Fasten three CORNER BRACKETS (T1) to the long edge of
the RIGHT UPRIGHT (E). Use three BLACK 1/2" PAN HEAD
SCREWS (S7).
å
NOTE: Be sure the edges of the BRACKETS are even with
the long edge of the RIGHT UPRIGHT.
å
Turn two PINS (Q1) into the RIGHT UPRIGHT (E) as shown.
Step 4
E
T1
BLACK 1/2" PAN HEAD SCREW
(3 used in this step)
S7
R1
F1
Q1
Q1
Page 8 www.sauder.com 402159
G1
(3 used)
