Step 10
å
Insert a SLIDE CAM (10A) into the DRAWER SIDES (D20 and D21).
å
Fasten the DRAWER RIGHT (35DC) and DRAWER LEFT (35DD)
to the DRAWER SIDES (D20 and D21). Use four GOLD 5/16" FLAT
HEAD SCREWS (3S) through holes #1 and #3.
å
NOTE: The screw head in the CAM must be visible through the
slotted hole in the SLIDE.
411606 www.sauder.com/servicePage 14
10A
10A
3 5 D C
35DC
3 5 D D
35DD
Screw head - turn CAM to line
up the holes in the SLIDES with
holes in the DRAWER SIDES.
1
2
3
1
2
3
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
Roller end
Roller end
D20
D21
