Sauder 411606 - Drawer

Step 9
411606www.sauder.com/service
Page 13
VIEW THE T-LOCK BOX VIDEO
å
Fasten the DRAWER BACK (D148) to the DRAWER
SIDES (D20 and D21). Use four BLACK 1-9/16" FLAT
HEAD SCREWS (30S).
å
NOTE: Be sure the DRAWER BOTTOM (D951) inserts into
the groove of the DRAWER BACK (D148).
12
3
å
Insert the DRAWER SIDES (D20 and D21) at an angle
into the slot at each end of the DRAWER FRONT (K2).
å
Slide the DRAWER BOTTOM (D951) into the grooves in the
DRAWER SIDES (D20 and D21) and DRAWER FRONT (K2).
The tabs should insert freely
into the slots. Gently tilt the
DRAWER SIDES side to side
until the tabs slip into the slots.
Groove
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT groove.
D20
D21
D951
D951
D20
D21
D148
D21
K2
K2
Unfi nished
surface
With the palm of your
hand, tap the DRAWER
BOTTOM down into
the groove.
D20
Start each screw a few turns before
completely tightening any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(4 used in this step)
30S
