Sauder 411606 - Tack

å
Fasten the RIGHT END (A3) to the TOP (E2) and BOTTOM (F3).
Tighten two HIDDEN CAMS and use two BLACK 1-15/16" FLAT
HEAD SCREWS (113S).
å
With a hammer, tap six TACK GLIDES (12E) into the bottom
edges of the ENDS (A3 and B3) and UPRIGHT (C3).
Step 7
411606www.sauder.com/service
Page 11
A3
C3
B3
F3
12E
12E
Arrow
Minimum
190 degrees
Maximum
210 degrees
BLACK 1-15/16" FLAT HEAD SCREW
(2 used in this step)
113S
Surface without HIDDEN CAMS
Unfi nished edge
Tighten two
HIDDEN CAMS
E2
